S100 Catv Cable Tv Handle Digital Signal Level MeterS100

This product applies to the need of the television and cable television engineering installation and detection, it is the high-performance surveying instrument specially designed for the cable television technical personnel.

Small volume, light weight, strong design, more than 6 hours of continuous use time

TFT color screen multifunction display, easy operation, the picture more clearly

Digital average power a key measurement, center frequency automatic switching

Double channel measurement display, easy to use

C/N, N/A, slope, mains voltage measurement, function of qi, the whole human activity battery compartments


Frequency Range 46MHz~870MHz

Channel: U.S. Standard Channel USA STD-CATV
U.S. digital standard channels USA STD-CATV
Measurement accuracy  ±50ppm(25℃±5℃)
Resolution  50KHz
Measurement bandwidth  280KHz±50KHz
Frequency interval  50KHz,100KHz,1MHz,10MHz,100MHz
Level Range  30~120dBuV
Level measurement accuracy  ±1.5dB (25℃±5℃)
Digital average power measurement range  30~115dBuV
Digital average power measurement accuracy  ±1.5dB (25℃±5℃)
Level measurement Resolution  0.1dBuV
Detection method  peak detection
Input Impedance  75Ω
Voltage measurement Input range  0~100VAC
Voltage Measurement accuracy  ±2V
Voltage Resolution  1V
Carrier to noise ratio measurement range
75~105dBuV
Dimensions  160mm×130mm×65mm
Total Weight  >600g
Audio output
Built-in speaker
charging time  > 6 hours
