Adhesive Big Barrel Liquid Filling Machine

Adhesive Big Barrel Liquid Filling Machine

Introduction
Liquid Filling Machine (Drum) is mainly used in industries such as coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fine chemical etc. It is suitable for filling liquid, ointment products.

Features
It adopts weighing type filling, so the filling accuracy is high and the filling will not be affected by different materials. It consists of two filling valves (Fast Fill and Slow Fill), which only can speed up filling speed but also increase filling accuracy. Its measure error is ±0.2%. Filling head adopts anti-drip device. The filled materials are without bubbles generated and with good effect. Material filling is automatically controlled. Pneumatic lid-clamping and lid-pressing device are optional.

Specification

• Power supply:220V,50/60Hz

• Filling speed:10-100 drums/h

• Filling error:±0.2%

• Air Consumption:Flux 0.1m³/h, pressure 0.4~0.6MPa

• Working temperature:0°C~40°C

• Inlet:DN50~DN100

• Filling range:50-1000L

• Materials:Wetted part of SS304 or SS316L

• Environment requirement:Explosive proof or Non explosive proof

• Capping device:Pneumatic lid-spinning device

Application

Coating, paint, printing ink, dye, pigment, adhesive, pesticide etc

Custom designs are also available
