Home > Products > shaft collar > Set Screw Shaft Collar Stop, Stainless Steel, 5/8" Bore, 1-1/8" OD,1/2" Width
Set Screw Shaft Collar Stop, Stainless Steel, 5/8" Bore, 1-1/8" OD,1/2" Width
USD $0.25 - $0.25
/ Piece
100 Pieces(Min.Order)
- 5000000 Piece / Pieces per Month
- Shanghai
- Credit Card
You May Like
-
standard 1-piece clamping collar shaft collar locking collar support small quantity
-
Inch shaft collar, shaft locking collar,steel shaft collar,set screw shaft collar
-
high quality non-standard flexible shaft coupling from reliable supplier in china
-
1/8" inch set screw shaft collar with zinc plated
-
Custom made one piece clamp collar
-
steel black oxide 2-piece clamping collar
Product Details
| Structure | Disc | Flexible or Rigid | Flexible | |
| Standard or Nonstandard | Nonstandard | Material | Steel | |
| Brand Name | JY | Place of Origin | Zhejiang, China | |
| Model Number | JY001 |
Product Description
Shaft Collar with znic plated:
| Set Screw Collar Specification | ||||
| Steel Collar | Bore(inch) | OD(inch) | Width(inch) | Set Screw |
| SC-3-F | 0.1875 | 7/16 | 0.25 | #8-32X1/8 |
| SC-4-F | 0.25 | 1/2 | 0.281 | #8-32X1/8 |
| SC-5-F | 0.3125 | 5/8 | 0.344 | #10-32X5/32 |
| SC-6-F | 0.375 | 3/4 | 0.375 | 1/4-20X3/16 |
| SC-7-F | 0.4375 | 7/8 | 0.438 | 1/4-20X1/4 |
| SC-8-F | 0.5 | 1 | 0.438 | 1/4-20X1/4 |
| SC-9-F | 0.5625 | 1 | 0.438 | 1/4-20X1/4 |
| SC-10-F | 0.625 | 1 1/8 | 0.5 | 5/16-18X1/4 |
| SC-11-F | 0.6875 | 1 1/4 | 0.563 | 5/16-18X1/4 |
| SC-12-F | 0.75 | 1 1/4 | 0.563 | 5/16-18X1/4 |
| SC-13-F | 0.8125 | 1 5/16 | 0.563 | 5/16-18X1/4 |
| SC-14-F | 0.875 | 1 1/2 | 0.563 | 5/16-18X5/16 |
| SC-15-F | 0.9375 | 1 5/8 | 0.563 | 5/16-18X5/16 |
| SC-16-F | 1 | 1 5/8 | 0.625 | 5/16-18X5/16 |
| SC-17-F | 1.0625 | 1 3/4 | 0.625 | 5/16-18X5/16 |
| SC-18-F | 1.125 | 1 3/4 | 0.625 | 5/16-18X5/16 |
| SC-19-F | 1.1875 | 2 | 0.688 | 3/8-16X3/8 |
| SC-20-F | 1.25 | 2 | 0.688 | 3/8-16X3/8 |
| SC-21-F | 1.3125 | 2 1/8 | 0.688 | 3/8-16X3/8 |
| SC-22-F | 1.375 | 2 1/8 | 0.75 | 3/8-16X3/8 |
| SC-23-F | 1.4375 | 2 1/4 | 0.75 | 3/8-16X3/8 |
| SC-24-F | 1.5 | 2 1/4 | 0.75 | 3/8-16X3/8 |
| SC-26-F | 1.625 | 2 1/2 | 0.813 | 3/8-16X3/8 |
| SC-28-F | 1.75 | 2 3/4 | 0.875 | 1/2-13X1/2 |
| SC-31-F | 1.9375 | 3 | 0.875 | 1/2-13X1/2 |
| SC-32-F | 2 | 3 | 0.875 | 1/2-13X1/2 |
| SC-33-F | 2.0625 | 3 | 0.875 | 1/2-13X1/2 |
| SC-34-F | 2.125 | 3 | 0.875 | 1/2-13X1/2 |
| SC-35-F | 2.1875 | 3 1/4 | 0.938 | 1/2-13X1/2 |
| SC-36-F | 2.25 | 3 1/4 | 0.938 | 1/2-13X1/2 |
| SC-38-F | 2.375 | 3 1/4 | 0.938 | 1/2-13X1/2 |
| SC-39-F | 2.4375 | 3 1/2 | 1 | 1/2-13X1/2 |
| SC-40-F | 2.5 | 3 1/2 | 1 | 1/2-13X1/2 |
| SC-44-F | 2.75 | 4 | 1.125 | 1/2-13X5/8 |
| SC-47-F | 2.9375 | 4 1/4 | 1.125 | 1/2-13X5/8 |
| SC-48-F | 3 | 4 1/4 | 1.125 | 1/2-13X5/8 |
| SC-55-F | 3.4375 | 4 3/4 | 1.125 | 1/2-13X5/8 |
| SC-56-F | 3.5 | 4 3/4 | 1.125 | 1/2-13X5/8 |
| SC-63-F | 3.9375 | 5 1/4 | 1.125 | 1/2-13X5/8 |
| SC-64-F | 4 | 5 1/4 | 1.125 | 1/2-13X5/8 |
Product show:
Inspection:
In our factory , we only use Mitutoyo to inspect!!!
Raw Material:
20 years OEM shaft set collor, we choose the best seamless tube as raw material.
With 300 tons various of seamless tube in stock, we can meet you most request of shaft collar and sleeve bushing.
Equipment List:
| No | Equipment Name | Quantity In Useing |
| 1 | 25Ton Stamping Machine( World) | 3 |
| 2 | 45Ton Stamping Machine( World) | 3 |
| 3 | 60Ton Stamping Machine( World) | 1 |
| 4 | 80Ton Stamping Machine( World) | 1 |
| 5 | 16Ton Stamping Machine( World) | 4 |
| 6 | 10Ton Stamping Machine( World) | 3 |
| 7 | 250Ton Stamping Machine( World) | 1 |
| 8 | 35Ton Precision Stamping Machine( SEYI) | 13 |
| 9 | 45Ton Precision Stamping Machine( SEYI) | 3 |
| 10 | 110Ton Precision Stamping Machine( SEYI) | 2 |
| 11 | 160Ton Precision Stamping Machine( SEYI) | 2 |
| 12 | YF32-100 four column universal hydraulic press | 2 |
| 13 | CK6136S CNC lathe | 25 |
| 14 | C0625 instrument lathe | 15 |
| 15 | MT1050A centerless grinder | 8 |
| 16 | 2512B drilling machine | 8 |
| 17 | WC67Y-100/3200 hydraulic bending machine | 1 |
| 18 | GZ4232 NC saw machine | 2 |
| 19 | 3mm steel plate shearer | 1 |
| 20 | CNC pipe cutter | 8 |
| 21 | welding manipulator (Panasonic) | 1 |
Seeing is Believing , welcome to visit our factory
