Steel Pressed Korean Type Right Angle Coupler Scaffolding
- shangahi
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DH | |
| Model Number | 48.6 | Type | Scaffolding Parts | |
| Scaffolding Part Type | Scaffolding Couplers |
Product Description
Specifications
1. Steel Pressed JIS type right angle coupler scaffolding2. Size: 48.6*48.6mm
3. Weight: 650-580g
Steel Pressed Korean type scaffold coupler
Our factory was established in 1997. We specialize in the design, manufacture and marketing all kinds of pressed scaffolding clamps, couplers, non-standard fastener and OEM metal spare parts. All punching moulds and tools are made by us.
Our products have entered such countries and regions as Japan, Korea, Southeast Asia, South Asia, the Middle East and Western Europe. Our company can design and develop all kinds of top-grade coupler products according to the foreign customers' demands. These are the characters of our coupler:
1. Type: include Japanese type, Korean type, BS type. Swivel and Fixed type
2. size: from 42.7-76.2mm
3. thickness: from 2.5mm-5mm
4. weight : 580g-1050g
5. Surface: Zinc electroplate, or hot dipped
If you want to see more information about our products, you are welcome to vist my factory
Our couplers has passed the test in Singapore, test form as
| Sample Reference | swivel coupler | S311:2005 | |||
| set 1 | set2 | set3 | Requirment | ||
| Position A | 5 | 9 | 8 | shall not exeed | |
| Slip Test(mm) | Position B | 5 | 9 | 7 | 10mm at a tension |
| Position C | 9 | 6 | 8 | load of 7.35 kN | |
| Position D | 8 | 8 | 8 | ||
| Maximum Load(kN) | 13.44 | 13.29 | 13.59 | Min 9.81 | |
| Average Maximum Load(kN) | 13.44 | Min10.8 |
| Sample Reference | Fixed coupler | S311:2005 | |||
| set 1 | set2 | set3 | Requirment | ||
| Position A | 10 | 9 | 10 | shall not exeed | |
| Slip Test(mm) | Position B | 9 | 9 | 10 | 10mm at a tension |
| Position C | 9 | 8 | 9 | load of 9.8kN | |
| Position D | 10 | 8 | 9 | ||
| Maximum Load(kN) | 15.3 | 15.87 | 16.36 | Min 14.7 | |
| Average Maximum Load(kN) | 15.84 | Min 15.7 |
