Pressed JIS Type Scaffolding Galvanized Pipe Clamps
- Shanghai
- T/T D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DH | |
| Type | Scaffolding Parts | Scaffolding Part Type | Scaffolding Couplers |
Product Description
Specifications
1. Pressed JIS type scaffolding galvanized pipe clamps2. 48.6*48.6mm
3. 650g, 620g, 580g
4. Zinc finish
Our factory has more than 15 years experience on pressed scaffolding coupler production. We have several kinds of scaffolding couplers, includes Japanese type, Korean type, British type, and so on.
1. Size of JIS swivel scaffolding coupler: 42.7, 48.6, 60.5, 76.2mm.
2. Thickness: 2.5, 2.75, 3.0mm
3. Weight : 580g~750g
4. Type: pressed coupler, include fixed and swivel type
5. Finish: Zinc electroplate, hot dipped
6. All moulds are made by ourselves, we can design products according to your order.
Our couplers has passed the test in Singapore, test form as
| Sample Reference | swivel coupler | S311:2005 | |||
| set 1 | set2 | set3 | Requirment | ||
| Position A | 5 | 9 | 8 | shall not exeed | |
| Slip Test(mm) | Position B | 5 | 9 | 7 | 10mm at a tension |
| Position C | 9 | 6 | 8 | load of 7.35 kN | |
| Position D | 8 | 8 | 8 | ||
| Maximum Load(kN) | 13.44 | 13.29 | 13.59 | Min 9.81 | |
| Average Maximum Load(kN) | 13.44 | Min10.8 |
