Home > Products > Pulp Juice FIlling Machine > Full Automatic Grain Juice Filling Machines 4in1
Full Automatic Grain Juice Filling Machines 4in1
- shanghai port
- T/T
You May Like
-
Juice Drink Hot Filling Machines 4in1 Production Line
-
Bottle Juice Grain Hot Filling Machines Production
-
Grain Juice Soft Drink Hot Filling Machines Zhangjiagang
-
Botted Grain Juice Filling Machine Pulp Juice Filling Machine
-
Pulp Juice Bottling Filling Packing Machine
-
Apple Juice Production Line/ Natural Fresh Fruit Juice Filling Machine
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 5.5-12KW | |
| Place of Origin | Jiangsu, China | Brand Name | XINMAO | |
| Model Number | KLR | Dimension(L*W*H) | 2800*1720*2200 | |
| Weight | 2800-12000kg | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
full automatic grain juice filling machines 4in1
Main features of the equipments:
1)Using the wind sent access, with clamp hanging the bottle neck ; which can keep the bottle shape and high-speed.
2)Washing bottle mouth with special designed washing manipulator,clip in the bottle neck, stable and avoid secondary pollution.
3)Grain filling uses measuring cup to quantify, ensure grain uniformity.
4)Capping adopts French advanced technology, cap sorter install in a lower position, send cap in level position.
5)Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Technical data | ||||
Model | CGF14125 | CGF18186 | CGF24248 | CGF323210 |
Number of washing, filling, capping | 14-12-5 | 18-18-6 | 24-24-8 | 32-32-8 |
Capacity; bottle(600ml)/hour | 3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
Suitable bottle size (mm) | φ=50-108 H=170-340 330ml-2.25L | |||
Pressure (kg/cm2) | 2~3 | |||
Power (kw) | Total motor 4.5kw | Tota motor 4.5kw | Tota motor 6kw | Tota motor 8kw |
Overall size (mm) (LxWxH) | 2100x1400x2500 | 2460x1720x2650 | 3100x2100x2650 | 3500x2500x2650 |
Weight(kg) | 2500 | 3500 | 4200 | 5500 |
Pictures :
factory show:
if you have any questions about this machine,please contact to us without hesitation.
skype : beveragemachine1
mobile:0086-18962226129
