OEM/ODM 3.5 Inch Resisitive Diaplay Screen Monitor for Security Monitoring
- 500000 Piece / Pieces per Month
- SHENZHEN/HONGKONG
- Credit Card
You May Like
-
Shenzhen Suppler Ckingway 6.95 Inch Resisitive Touch Panel Display use for Security Monitoring System
-
OEM/ODM 3.5 Inch Resisitive Touch Panle Screen for Security Monitoring
-
Ckingway 10 Inch Resistive Touch Panel Display Controller for Security Monitoring
-
Ckingway touch panel Display Screen Sztp1263-7-W5r for Security Monitoring System
-
High Resolution touch sensor screen for Security Monitoring
-
Cheap 7 inch Film+Glass Resistive touch panel cover glass for Security Monitoring
Product Details
Products Status | Stock | Screen Size | Other, 3.5" inch | |
Type | Other, Resistive, 4 Wire Restistive Touch screen | Interface Type | USB | |
Resolution | Other, 4096*4096, 4096*4096 | Brand Name | CKINGWAY | |
Model Number | SZTP1208-3.5 | Place of Origin | Guangdong, China |
Product Description
Product Description
The Feature of OEM/ODM 3.5 Inch Resisitive Diaplay Screen Monitor for Security Monitoring as below:
1.Low cost solution, Low power consumption
2. Consistently accurate, fast touch response
3. Pressure sensitive, works with any stylus, Finger, gloved hand and stylus activation
4. Not affected by dirt, dust, water, or light
5. Affordable touch screen technology
6. Antiglare surface treatment
4 wire restistive touch screen technology:
Ckingway 4-Wire Resistive products are perfect for industry machine GPS System or portable products where compact size and low power draw is a priority – such as PDAs, GPSs, smart phones and other hand-held applications. Our pressure sensing 4-wire resistive touch screens are cost effective and allow for input versatility with bare or gloved fingers and any pointing device.
Backed by a one-year warranty and 5 million touches in a single location, Touch International’s 4-Wire resistive touch screens allow for ease of integration and use.
Size | 3.5" inch |
Structure | PET + Film + Film + Glass |
Connector | Pin 4 plug connector |
Thickness | 1.4 ± 0.15 mm |
Touch Media | Finger, Touch Pen |
Type | 4 Wire Restistive Touch screen |
Ratio | 16:9 |
Resolution | 4096*4096 |
Response Time | ≤ 10 ms |
Supply Voltage | 5V DC , 35 mA |
Transparent | ≥ 78% |
Screen Resistance | X:100-500Ω Y:200-1000Ω |
Insulation Resistance | ≥20MΩ(10V DC) |
Pressure | 50 - 150 g |
Surface Hardness | 3H |
Life Span | > 1,000,000 time knocking ; ≥ 100,000 time in paddling |
Operating Temperature | — 10℃ ~ +60℃ |
Storage Temperature | — 20℃ ~ +70℃ |
Storage Humidity | 20 ~ 85% RH (except congeal fog) |
Custom Service | Available |
OEM/ODM 3.5 Inch Resisitive Diaplay Screen Monitor for Security Monitoring for Packing:
Anti-Static Foam+Paper Card+Ragged Bag+Carton
OEM/ODM 3.5 Inch Resisitive Diaplay Screen Monitor for Security Monitoring for Term of payment:
1.Full payment before delivery
2.Prepay 30% as the deposite,T/T 70% the balance before delivery
3.Prepay 50% as the deposite and mould fee ,T/T 50% the balance before delivery
4.Payment method can be nogotiated
