Home > Products > Conduit Body > rigid conduit box C-sharped conduit bodies, die cast aluminum
rigid conduit box C-sharped conduit bodies, die cast aluminum
- shanghai ningbo
- T/T
You May Like
Product Details
| Place of Origin | Hubei, China | Brand Name | MEIDA | |
| Model Number | C | Material | Other |
Product Description
Model No.
| Trade SIZE |
length
| width | height | Color |
C-50 | 1/2" | 4-5/16" | 1-5/16" | 2-3/32" | GRAY |
C-75 | 3/4" | 5-3/32" | 1-9/16" | 2-3/8" | GRAY |
C-100 | 1" | 5-29/32" | 1-13/16" | 2-3/4" | GRAY |
C-125 | 1-1/4" | 7-13/16" | 2-1/2" | 3-1/2" | GRAY |
C-150 | 1-1/2" | 7-13/16" | 2-1/2" | 3-1/2" | GRAY |
C-200 | 2" | 10-1/16" | 3-3/16" | 4-1/2" | GRAY |
C-250 | 2-1/2" | 12-13/16" | 4-1/2" | 5-5/16" | GRAY |
C-300 | 3" | 12-13/16" | 4-1/2" | 5-29/32" | GRAY |
C-350 | 3-1/2" | 15-5/8" | 5-9/16" | 7-5/16" | GRAY |
C-400 | 4" | 15-5/8" | 5-9/16" | 7-5/16" | GRAY |
Specifications
1.material:Die cast Aluminum(ADC12)
2.with neoprene gasket or not
3.surface powder coated
4. size:1/2"-4"
5.C,T,LB,LL,LR types avaliable
Description
1.rugged,seamless,die-cast construction that prevents mositure entry
2.state of the art powder coat finish for maximum durability
3.Flat back design for easy mounting close to walls
4.may be used on aluminum or steel conduit
Applications
1.Threaded style conduit bodies are for use on rigid conduit
2.set-screw style are for use on thin wall(EMT)conduit
3.use TEDDICO/BWF conduit outlet bodies for connecting conduit sections,for making bends in conduit runs,as pull outlets,or to provide openings for making splics and taps in conductors
