Dongfeng DFL3250A 6x4 Engineering Dump Truck
- Shanghai
- T/T
You May Like
Product Details
| Drive Wheel | 6x4 | Capacity (Load) | 31 - 40t | |
| Horsepower | 351 - 450hp | Condition | New | |
| Transmission Type | Manual | Emission Standard | Euro 3 | |
| Fuel Type | Diesel | Engine Capacity | 6 - 8L | |
| Gross Vehicle Weight | 2650 | Place of Origin | China | |
| Brand Name | Dongfeng | Model Number | DFL3250A | |
| Dimensions (L x W x H) (mm) | 8020x2480x3220 |
Product Description
DFL3250A 6x4 Dongfeng Engineering Dump Truck
| Dimension | Overall dimension L*W*H(mm) | 8020×2480×3220 |
|
Inner Dimension of cargo body(mm) | 5500×2300×1500 |
| ||
Wheel Base (mm) | 3800+1350 |
| ||
F/R tread (mm) | 1986/1860 |
| ||
Appr./Depa. angel (°) | 32/36 |
| ||
| Curb (kg) | 11305 |
| |
Rated Payload(kg) | 21000-30000 |
| ||
|
|
|
|
|
| G.V.W (kg) | 26500 |
| |
Max. speed (km/h) | 78 |
| ||
Max. gradeability (%) | 25 |
| ||
Ground clearance (mm) | 237 |
| ||
Engine
| Type |
|
| |
Model | L375 30 |
| ||
Manufacturer | Dongfeng commins engine Co.,Ltd |
| ||
(ml | 8300 |
| ||
Fuel sort | Diesel |
| ||
(KW/r/min) | 275(KW) /2200(rpm) |
| ||
(Nm/r/min) | 1125(N.m) /1200~1400(rpm) |
| ||
(mm*mm) | 114×135 |
| ||
Compression ratio | 18:01 |
| ||
Emission Level | Euro III |
| ||
| Model | TJG160 |
| |
Type | Flat Head ,one and half Row |
| ||
Cab Allowed Capacity | 3 persons |
| ||
Number of Seat | 3 |
| ||
Air condition | With airconditioner |
| ||
Number of Door | 2 |
| ||
| Model | N/A |
| |
Driving from | 6×4 |
| ||
Number of axles | 4 |
| ||
Rim/Tire Type | 11.00R20 |
| ||
Number of Tires | 10 |
| ||
Clutch | Friction Plates Outer Diameter | Φ420mm |
| |
| Model | 9 speed |
| |
Type |
|
| ||
Forward Gear | 9 |
| ||
| Steering Mode |
|
| |
| Model | 7T |
| |
| Model | 13T*2 |
| |
|
| Type |
|
|
| 8 |
| ||
| Type |
|
| |
| 8/10 |
| ||
Chassis Frame | cross-section | 300×90×[8+8] mm |
| |
A/C | Air conditioner option |
|
| |
Nude cargo,container, the vehicle surface spray anti-rust wax ,we will provide the best break bulk carriers and Ro-Ro shipping scheme according to your actual situation.
1. Factory Supply:
A). the biggest and famous vehicle manufacturer in china,
B). more than 300 kinds of special truck for your selecting.
2. OEM Ability: can be made according to your requirements, the material, the size, the color and the logo can be optional.
3. Good Quality:
A). has solid technology, advanced equipments; reliable quality and flexible modes of operation also have strict quality control system,
B). ISO9001-2008 standard and the 3C (China Compulsory Certification),
C). China top brand with good reputation at home and abroad.
4. Good Service: 24-hour hotline and email.offer quickly no more than 5 minutes.
5. Fast Delivery: 10-35 days after payment, safe and quick delivery depends on your order quantity.
Hubei Global Industrial & Trade Co., Ltd
which is one of branches for famous vehicle manufacturer of Dongfeng Motor in China and producing all kinds of special-purpose vehicles.Our company has independent export qualification, and has a lot of customers from domestic and overseas. Our leading varieties include more than 200 types of trucks such as :
1) Bus series:
Minivan-minibus-tourist bus-city bus-school bus-off road bus-CNG bus-special bus.
2) Truck series:
Minitruck-light truck-heavy duty truck-dump truck-off road military orcivil truck-CNG truck-LNG truck-pickup truck- tractor truck.
3)Special-purpose truck series:
Ambulance truck-fire fighting truck-garbage truck-concrete mixer truck-refuse compactor-fecal suction truck-sewage suction truck-fuel tank truck-chemical liquid tank truck-high altitude operation truck- crane truck-instructional truck-van truck-livestock truck-mobile shop truck-refrigerator truck-water wagon-sprinlker truck-bulk cement truck-wrecker truck-sweeper truck-asphalt distributor truck-water well drilling rig-Armored truck-aircraft refueller-antiriot vehicles-Hummers and so on.
4) Chassis series:
Bus chassis-truck chassis-off road vehicle chassis-diesel or CNG/LNG chassis.
5) Trailer and semi-trailer series:
2 or 3 Axles flatbed semi-trailer/low flatbed semi-trailer/skeleton semi-trailer/container semi- trailer/sidewall semi- trailer/various tanker semi-trailer/dump semi-trailer/refrigerator semi-trailer/car and wood transport semi-trailer and so on.
6)Spare parts:
Whole vehicle spare parts.
Our company has solid technology, flawless inspection, advanced equipments, reliant quality and flexible modes of operation. What 's more , it has roundly passed the ISO9001-2000 and the 3C(China compulsory of certification).
Our survival is based on the quality and credit standing is the guarantee of our success. We will do as we can that treating customers honestly,managing flexibly, guaranteeing high quality but low price, and keeping high effeciency.We promise that all the products are adapted and sold by us can get warranty services for one year and enjoy maintenance for all life.What's more, Chinese mainland after service can be dealt with in 48hours.
Hereby, we warmly welcome new and old friends to vist our company at anytime, and hope we can have a good and win-win business relationship between us in the near future.
Thank you!
1. Price term: FOB Shanghai in China.CIF for destination port.
2. Payment: T/T 30% deposit after order confirmation, 70% balance cash before delivery.
3. Delivery time: 10-35 working days after payment is received.
4. Standard Steering:Left-hand drive, if you need Right-hand drive type, please inform us in advance, we can make the special order for you.
Once you have any inquiry about Dongfeng products in the following days,hope you could feel free to contact with us,wich is much appreciated.also welcome you and your team to China to visit our company,seeing is believing !
How to get to our city ? the flight line as following:
Flight line: you can fly from Shanghai/Beijing/Guangzhou or Shenzhen to Xiangyang airport of Hubei province,we can pick you up at the airport.
