GE IC697CGR935 Módulo de CPU de alto rendimiento

Frecuencia: Procesador PowerPC de 166MHz, que admite operaciones de coma flotante de 32 bits. La velocidad de ejecución de instrucciones alcanza 1,2μs por booleano, lo que permite el procesamiento rápido de lógica y algoritmos complejos.

Memoria: 2MB de memoria de usuario (expandible a 8MB), 512KB de RAM con respaldo de batería (que admite la retención de datos durante 6 meses), lo que satisface las necesidades de almacenamiento de programas y datos a gran escala.

Soporte de standby caliente: Admite la redundancia de standby caliente de doble CPU (se requiere software y racks redundantes). El espejado de datos en tiempo real entre las CPUs activa y en espera se logra a través de un bus de sincronización de alta velocidad, con un tiempo de conmutación de <10ms, ensuring uninterrupted transition in case of faults.

Dual-Bus Architecture: Built-in dual VME bus interfaces, with active and standby links operating independently, improving communication reliability.

Local I/O: A single rack supports up to 16 I/O modules. Remote racks can be connected via bus expansion modules (such as IC697BEM733/741), with the total number of I/O points reaching thousands.

High-Speed Processing: Supports special function modules such as high-speed counters and motion control, meeting the requirements of precision control.

Built-in Ports:

Expansion Options: Interfaces such as Profibus, DeviceNet, and fiber optic communication can be added through plug-in modules to meet diverse networking needs.

LED Status Indicators: Provide indicators for power, operation, communication, and faults, real-time feedback on module status.

Self-Diagnostic Function: Monitors the status of the CPU, memory, and communication links. In case of faults, it automatically records event logs and triggers alarms.

Hot-Swap Support: Allows live replacement of modules, reducing system downtime.

Temperature Range: Operating temperature from -20°C to 60°C; storage temperature from -40°C to 85°C.

Anti-Interference: Complies with industrial-grade EMC standards, resistant to vibration (5-2kHz, 1g) and shock (30g), adapting to harsh environments.

Higher Performance: The PowerPC processor provides twice the computing speed of the CGR772, suitable for large data processing and complex algorithms.

Rich Communication: Built-in Ethernet port and multiple serial ports can meet most networking needs without additional expansion.

Large-Capacity Memory: 2MB user memory supports more complex control programs and data storage.

Redundant Systems: Combine with IC697BEM741 redundant bus modules and dual power supplies to build a complete hot standby architecture.

Programming Software: Use GE Fanuc's Proficy Machine Edition or VersaPro for programming, supporting multiple languages such as ladder diagrams and function block diagrams.

Communication Optimization: Connect to HMI/SCADA systems through Ethernet ports, and use RS-485 ports to connect field devices to achieve hierarchical communication.
